TopChiller can design and manufacture all types of centrifugal chillers for you
- Cooling capacity ranges from 250 TR – 3500 TR
- Temperature control ranges from -6 to 15°C
- Semi-sealed branded centrifugal compressor
- Low ozone depletion potential & global warming
- Orifice plate expansion device reducing pressure
- Stainless steel tube type durable heat exchanger
- Shell and tube type heat exchanger & evaporator
- Reliable thermostat, motor valves, and strainers
Your Premier Centrifugal Chiller Manufacturer and Supplier in China
Centrifugal Chiller is a precisely designed cooling unit working on vapor-compression principle and releases out the collected heat by chilled water to the outside environment and again chilled the coolant from a cooling tower for continuous processing.
TopChiller is a leading manufacturing company of China among the best outstanding world enterprises that is supplying Centrifugal Chiller for over twenty years with sophisticated experience and credibility.
Since 1999, TopChiller is servicing the top industries around the world with superb fast and certified full stock of Centrifugal Chiller by keeping in view the requirements of customers and trending demands of the market.
Centrifugal Chiller is made of different reliable components as centrifugal compressor, thermostat, motor valves, air filters, tube type heat exchanger, shell and tube type condenser and evaporator, magnetic bearing, motor drive, and protection devices.
TopChiller designed Centrifugal Chiller is famous among different industrial processing providing several benefits to owners as given below.
- Centrifugal Chiller has long service life and energy-efficient performance configured by use of branded centrifugal compressor with high cooling capacity and is used as a most preferable unit for applications requiring high cooling effect configured by its large footprint.
- TopChiller engineered Centrifugal Chiller is highly fluent and instant in cooling production configured by the use of impellers attached to the compressor support to apply speeding force on refrigerant to flow quickly for heat release from the system.
- Centrifugal Chiller is applicable to use for an HVAC system having efficient working evaporator and heat exchanger configuring the management of cooling, humidity level, and heating inside the application according to ambient temperature.
- TopChiller designed Centrifugal Chiller is feasible and suited for indoor applications. It can be installed for indoor applications due to echo-friendly and wetted surfaces installation preventing the unit from rusting.
- Orifice expansion plates inside Centrifugal Chiller ensure to mitigate the pressure on condensed liquid for cycling again in unit coils.
Centrifugal Chiller is an energy-conserving unit that is used for an assorted number of applications as:
HVAC system, educational industries, laboratories, office buildings Airport cooling systems, commercial buildings as supermarkets, industrial plants, universities, cruise ships.
By keeping in view the above featuring of the unit, are you thinking to buy a reliable Centrifugal Chiller for your application?
Are you eagerly desiring a technologically innovative company manufacturing Centrifugal Chiller that will assist you to expand your business with the best supportive parameters?
TopChiller is the best with excellent quality and perfect servicing to choose from. TopChiller technocrats and personnel is waiting for your response. Make contact with our engineered employees and experts to get beneficial updates about Centrifugal Chiller.
TopChiller is expertise in servicing our clients to select the best Centrifugal Chiller that would be feasible for your application at little cost.
- Data Sheet
- Image Gallery
Centrifugal Chiller Technical Specifications | |||||||||||||||
Model Items | 500 | 550 | 600 | 650 | 700 | 800 | 900 | 1000 | 1100 | 1200 | 1300 | 1400 | 1500 | ||
Cooling Capacity | kW | 1760 | 1965 | 2130 | 2324 | 2497 | 2858 | 3224 | 3575 | 3953 | 4323 | 4665 | 4925 | 5350 | |
Input Power | kW | 288 | 320 | 348 | 381 | 406 | 467 | 526 | 586 | 647 | 704 | 761 | 805 | 874 | |
COP | kW/kW | 6.11 | 6.14 | 6.12 | 6.1 | 6.15 | 6.12 | 6.13 | 6.1 | 6.11 | 6.14 | 6.13 | 6.12 | 6.12 | |
kW/RT | 0.58 | 0.57 | 0.57 | 0.58 | 0.57 | 0.57 | 0.57 | 0.58 | 0.58 | 0.57 | 0.57 | 0.57 | 0.57 | ||
Condenser | Water Flow Rate | m³/h | 352 | 393 | 426 | 465 | 499 | 572 | 645 | 716 | 791 | 865 | 933 | 986 | 1071 |
Water Pressure Drop | kPa | 72 | 86 | 86 | 86 | 86 | 95 | 95 | 120 | 120 | 120 | 120 | 120 | 85 | |
Inlet/outlet Pipe | DN | 200 | 200 | 250 | 250 | 250 | 250 | 300 | 300 | 300 | 300 | 300 | 300 | 350 | |
Evaporator | Water Flow Rate | m³/h | 303 | 338 | 366 | 400 | 429 | 492 | 555 | 615 | 680 | 744 | 802 | 847 | 920 |
Water Pressure Drop | kPa | 70 | 80 | 80 | 80 | 80 | 91 | 91 | 116 | 116 | 116 | 116 | 116 | 76 | |
Inlet/outlet Pipe | DN | 200 | 200 | 250 | 250 | 250 | 250 | 300 | 300 | 300 | 300 | 300 | 300 | 350 | |
Dimension | Lengeth | mm | 3920 | 4120 | 4120 | 4120 | 4120 | 4480 | 4570 | 4870 | 4950 | 4950 | 5000 | 5000 | 5700 |
Width | mm | 2320 | 2320 | 2480 | 2480 | 2580 | 2650 | 2650 | 2650 | 2850 | 2850 | 2900 | 3000 | 5300 | |
Height | mm | 2450 | 2450 | 2500 | 2500 | 2500 | 2740 | 2800 | 2800 | 2850 | 2850 | 2900 | 2900 | 2740 | |
Installation Dimension | mm | 2944 | 3144 | 3144 | 3144 | 3144 | 3384 | 3384 | 3684 | 3684 | 3684 | 3684 | 3684 | 3384 | |
mm | 1800 | 1800 | 1800 | 1800 | 2000 | 2000 | 2000 | 2050 | 2300 | 2300 | 2300 | 2400 | 4450 | ||
Net Weight | kg | 9100 | 9600 | 10100 | 10600 | 11200 | 11800 | 12500 | 13200 | 14500 | 15500 | 16500 | 18000 | 23200 | |
Running Weight | kg | 9100 | 10550 | 11100 | 11700 | 12350 | 13100 | 14000 | 14800 | 16350 | 17500 | 18600 | 20000 | 25700 | |
Refrigerant | kg | 450 | 495 | 540 | 585 | 630 | 720 | 810 | 900 | 990 | 1080 | 1170 | 1260 | 1350 | |
Centrifugal Chiller Technical Specifications | |||||||||||||||
Model Items | 1600 | 1700 | 1800 | 1900 | 2000 | 2100 | 2200 | 2300 | 2400 | 2500 | 2600 | 2700 | 2800 | ||
Cooling Capacity | kW | 5716 | 6082 | 6448 | 6799 | 7150 | 7528 | 7905 | 8276 | 8645 | 8988 | 9330 | 9590 | 9850 | |
Input Power | kW | 932 | 992 | 1054 | 1110 | 1168 | 1230 | 1292 | 1350 | 1410 | 1467 | 1525 | 1567 | 1610 | |
COP | kW/kW | 6.13 | 6.13 | 6.12 | 6.13 | 6.12 | 6.12 | 6.12 | 6.13 | 6.13 | 6.13 | 6.12 | 6.12 | 6.12 | |
kW/RT | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | 0.57 | ||
Condenser | Water Flow Rate | m³/h | 1143 | 1217 | 1290 | 1360 | 1431 | 1506 | 1582 | 1656 | 1729 | 1798 | 1867 | 1919 | 1971 |
Water Pressure Drop | kPa | 85 | 85 | 85 | 85 | 105 | 105 | 105 | 105 | 105 | 105 | 105 | 105 | 105 | |
Inlet/outlet Pipe | DN | 350 | 350 | 350 | 350 | 400 | 400 | 400 | 400 | 450 | 450 | 450 | 450 | 450 | |
Evaporator | Water Flow Rate | m³/h | 983 | 1046 | 1109 | 1169 | 1230 | 1295 | 1360 | 1423 | 1487 | 1546 | 1605 | 1649 | 1694 |
Water Pressure Drop | kPa | 76 | 76 | 76 | 76 | 95 | 95 | 95 | 95 | 95 | 95 | 95 | 95 | 95 | |
Inlet/outlet Pipe | DN | 350 | 350 | 350 | 350 | 400 | 400 | 400 | 400 | 450 | 450 | 450 | 450 | 450 | |
Dimension | Lengeth | mm | 5700 | 5700 | 5700 | 5700 | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 |
Width | mm | 5300 | 5300 | 5300 | 5300 | 5750 | 5750 | 5750 | 5750 | 5850 | 5850 | 5850 | 6000 | 6000 | |
Height | mm | 2740 | 2800 | 2800 | 2800 | 2800 | 2850 | 2850 | 2850 | 2850 | 2900 | 2900 | 2900 | 2900 | |
Installation Dimension | mm | 3384 | 3384 | 3384 | 3384 | 3684 | 3684 | 3684 | 3684 | 3684 | 3684 | 3684 | 3684 | 3684 | |
mm | 4450 | 4450 | 4450 | 4450 | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 | 5200 | 5200 | ||
Net Weight | kg | 23600 | 24300 | 25000 | 25700 | 26400 | 27700 | 29000 | 30000 | 31000 | 32000 | 33000 | 34500 | 36000 | |
Running Weight | kg | 26500 | 27100 | 28000 | 28800 | 29600 | 31150 | 32700 | 33850 | 35000 | 36100 | 37200 | 38600 | 40000 | |
Refrigerant | kg | 1440 | 1530 | 1620 | 1710 | 1800 | 1890 | 1980 | 2070 | 2160 | 2250 | 2340 | 2430 | 2520 |
