TopChiller can design and manufacture all types of modular chillers for you
- Cooling capacity ranges from 10 Ton to 200 Ton
- Heating capacity ranges from 20 KW to 360KW
- Temperature control ranges from 7°C to 35°C
- Reliable semi-hermetic branded scroll compressor
- V- Shape condenser & shell type heat exchanger
- Control panel electric heater with thermostat
- Automatic circuit breaker, water pumps, EC fans
- Precise expansion valves & condenser fans
Your Premier Modular Chiller Manufacturer and Supplier in China
A Modular Chiller is a central air conditioning unit that configures different chiller modules in a series or parallel way and uses air for cooling or heating purpose with chilled glycol or water circulation.
TopChiller is a reliable multi-brand commercial manufacturer and supplier company of China working over the last twenty years and successfully serving our customers by providing a large variety of Modular Chiller in diverse global markets.
Since 1999, TopChiller is keenly working to maintain its robust presence in the global world by manufacturing innovative, reliable, and precise Modular Chiller full stock with customized services and solutions.
Modular Chiller constitutes of different branded components as hermetic scroll compressor, V-shape condenser, condenser fans, water pumps, automatic circuits, expansion valves, heater, thermostat, temperature regulator, condenser blades, power supply, and protecting devices.
TopChiller brand Modular Chiller regulates the heating and cooling level of a machine with a diverse number of benefits as given below:
- Modular Chiller has a specific design and versatility in its operation featured by some heating units to produce a heating effect as heater, and thermostat. Similarly, chilled glycol circulation and condenser produce a cooling effect inside the unit.
- TopChiller engineered Modular Chiller has a large ranged cooling capacity configured by the use of more than one module working independently and provides high cooling capacity for large-sized applications.
- Modular Chiller with multi modules installation is connected to one point power supply ensuring maintenance of the whole unit, All modules work together but independently. If one module may damage another one will continue its working.
- TopChiller brand Modular Chiller diligently works for air conditioning system featured by fans coil units, and air handling unit that ensures the cooling and heating concerning machine requirements.
- Modular Chiller is easy to install for a variety of applications configured by no use of water tanks but just water pipelines providing chilled water for cooling effect.
Modular Chiller is versatile for its dual featuring and used for different industrial applications as:
Heating pumps cooling, skating rinks, hospitals, computer room air conditioning, plastic manufacturing, landfill gas cooling, injection molding, villas, hotels, office buildings, restaurants, supermarkets, and movie theaters.
If you have intentions to purchase a highly precise and optimal Modular Chiller for improving the working of your application?
If you are persistently in quest of the best trustworthy company in China manufacturing Modular Chiller for the betterment of your business?
You are leading the right way.TopChiller is best to rely on its worldwide publicity. TopChiller has hired trained engineers and experts for customized services.
Approach to TopChiller staff and get a buying guide about the Modular Chiller best suited to your application at smart prices as well as other maintenance and technical assistance.
- Data Sheet
- Image Gallery
- Main Parts
| Modular Chiller Technical Specifications | ||||||||||
| Model. LSQW | 60×1 | 60×2 | 60×3 | 60×4 | 60×5 | 60×6 | 60×7 | 60×8 | ||
| Cooling capacity* | kW | 65 | 130 | 195 | 260 | 325 | 390 | 455 | 520 | |
| Heating capacity** | kW | 70 | 140 | 210 | 280 | 350 | 420 | 490 | 560 | |
| Compressor | Power supply | 380/3+N/50 | ||||||||
| Qty/refrigerant circuit | Nr. | 2/2 | 4/4 | 6/6 | 8/8 | 10/10 | 12/12 | 14/14 | 16/16 | |
| Cooling power input* | kW | 10.2×2 | 10.2×4 | 10.2×6 | 10.2×8 | 10.2×10 | 10.2×12 | 10.2×14 | 10.2×16 | |
| Heating power input** | kW | 10.0×2 | 10.0×4 | 10.0×6 | 10.0×8 | 10.0×10 | 10.0×12 | 10.0×14 | 10.0×16 | |
| Max. power input | kW | 39.92×1 | 39.92×2 | 39.92×3 | 39.92×4 | 39.92×5 | 39.92×6 | 39.92×7 | 39.92×8 | |
| Max. input current | A x nº | 38.8×1 | 38.8×2 | 38.8×3 | 38.8×4 | 38.8×5 | 38.8×6 | 38.8×7 | 38.8×8 | |
| Max. starting current **** | A | 142×1 | 142×2 | 142×3 | 142×4 | 142×5 | 142×6 | 142×7 | 142×8 | |
| Energy adjustment | % | 0-50-100 (Single unit) | ||||||||
| Axial fan | Quantity | Nr. | 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 |
| Airflow | m3/h | 29200 | 58400 | 87600 | 116800 | 146000 | 175200 | 204400 | 233600 | |
| Evaporator | Type | Tube in tube heat exchanger | ||||||||
| Water flow | m3/h | 11.17 | 22.34 | 33.51 | 44.68 | 55.85 | 667.02 | 78.19. | 89.36 | |
| Water side pressure drop *** | kPa | <<<- – – From 43 to 46 – – ->>> | ||||||||
| Water connection size | DN | 125 | ||||||||
| Power supply | / | 380V/3Ph/50Hz | ||||||||
| Noise level*** | V type coil | dB(A) | 71 | 72 | 73 | 74 | 75 | 76 | 77 | 78 |
| Dimensions V type coil | Length | mm | 2000 (Single unit) | |||||||
| Width | mm | 1060 (Single unit) | ||||||||
| Height | mm | 1957 (Single unit) | ||||||||
| Net weight | V type coil | kg | 630×1 | 630×2 | 630×3 | 630×4 | 630×5 | 630×6 | 630×7 | 630×8 |
| * Ambient temperature 35ºC; evaporator water in/out 12/7 ºC; | ||||||||||
| ** Ambient temperature DB 7 ºC, WB 6 ºC; condenser water in/out temperature 40/45 ºC; | ||||||||||
| *** In the nominal water flow condition the pressure drop is between this range. | ||||||||||
| **** Sound pressure measured at a distance of 1 m and a height of 1.5 m above the ground in a dear field. | ||||||||||
